* TAƎS Rally Clock – USB fitting

Description

6 digit red LED Rally Clock – all you need for most events, especially when starting out.

NEW – comes with strip of self adhesive velcro for ease of mounting

Clock retains the time when not powered.

Comes fitted with USB plug but can be used with or without, will operate on 5-15v so can run directly from an in car 12v supply, simply cut the plug off not required.

Red LEDs are visible even in bright sunlight but being a sensible size are not overly bright or distracting at night.

Lightweight, easy to mount
Adjustable brightness – option to dim from 19:00 – 07:00 automatically
Small foot print – fit anywhere
6 digit HH:MM:SS

0.36 inch 6-bit Clock LED Digital Electronic Clock W second display Module power off memory Brightness adjustment dc 5V 12V

Module parameters:

Dimensions:64*18*18mm(L x W x D)

Power supply voltage: DC 5~15V

Power supply current: 10~20ma

Time display format: 24 hours

NEW – comes with strip of self adhesive velcro for ease of mounting

How to set the time, date and automatic brightness function.

In the normal display state, press and hold the setting key at the top of the case for more than 1 second to enter the time adjustment function.

When the hour value starts to blink, short press the key to change the value, long press the key to enter the minute adjustment, when the minute value starts t0 blink, short press the key to change the value.

After setting for minutes, long press the button to enter the second adjustment, and short press the button to return to zero.

After the setting the time, long press the button to enter the brightness adjustment function, LL: 3 is displayed, short press the key to change the brightness. Then long press the key to enter the automatic brightness function switch setting, display AL: x, short press the key to change the value, AL :O is off, AL: 1 is on, when on the display will automatically change to level 1 brightness after 19:00 in the evening, and automatically change to the brightness value in the Ld setting after 7:00 in the morning. Finally, press and hold the key to save the Settings and exit the Settings.
